Audio Over IP
TERRA-FXO | IP to Telecom Gateway
Features
Specifications
Applications
Models
Features
Full Duplex IP Terminal to Telecom Gateway
The TERRA-FXO offers full duplex communication for IP intercom and telephone, it comes with 2 sets of telephone interfaces and DTMF management for receiving calls or broadcasting.
Specifications
TERRA-FXO Specifications
- SNMP (Simple Network Management Protocol) for device management on IP Networks
- PoE or 24 VDC power supply (if PoE is not available)
- 2 sets of telephone lines interface
- Full duplex with Acoustic Echo Cancellation and Noise Reduction
- Web browser interface for device management and monitor
- Internal 80MB storage for recoding, message storage
- RS232 or RS485 for 3rd party control
- Power LED and Status LED indicators
- Power consumption: 2.66W
- Weight: 0.95 lbs (430g)
- Dimensions (D x H x W): 4.1″ x 1.3″ x 4.3″ (104 x 32 x 109 mm)
- Supported audio codec:
- SIP: G.711 ulaw, G.711 alaw, G.722, G.726-32, G.727-32, G.729, PCM16K
- Record: G.711 ulaw, G.711 alaw, G.722, WAV, MP3
Applications
TERRA-FXO Applications
Synoptic Application
Models
TERRA-FXO Models
| TERRA-FXO | Analog phone interface x 2, RS232 x 1 |
| TERRA-FXO4 | Analog phone interface x 2, RS485 x 1 |
