TERRA-IEX | IP Audio Encoder/Decoder
Features
Specifications
Applications
Models
Features
Full Duplex IP Audio Encoder/Decoder
The TERRA-IEX is a 2 channel audio over IP encoder/decoder which operates as an audio source for an IP network. It comes with 2 independent balanced line outputs for full duplex communication for paging and broadcasting.
By using the optional USB interface, the playlists shall be used as a backup of the decoded stream or as a source for the IP streaming.
Specifications
TERRA-IEX Specifications
- 2 Mic/line balanced input
- 2 balanced line outputs (1 stereo or 2 mono)
- 1 stereo line input (3.5 mm mini-jack) for headphone
- Frequency response: 20 Hz ~ 20 kHz
- PoE or 24 VDC power supply (if PoE is not available)
- Web browser interface for device management and monitor
- SNMP (Simple Network Management Protocol) for device management on IP networks
- Optional USB 2.0 interface for music/message storage, playback and recording (TERRA-IEXU and TERRA-IEXU4)
- Power LED and Status LED
- 3 contact inputs and 1 contact output
- RS232 or RS485 for 3rd party control
- Power consumption: 3W
- Weight: 0.95 lbs (433g)
- Dimensions (D x H x W): 4.1″ x 1.3″ x 4.3″ (104 x 32 x 109 mm)
- Supported audio codec:
- SIP: G.711 ulaw, G.711 alaw, G.722, G.726-32, G.727-32, G.729, PCM16K
- SHOUTcast / icecast: MP3, AAC+
- Stream: G.711 ulaw, G.711 alaw, G.722, WAVE, MP3, PCM16K
- Record: G.711 ulaw, G.711 alaw, G.722, WAV, MP3
Applications
TERRA-IEX Applications
PA and BGM Application
Models
TERRA-IEX Models
Please note the TERRA-IEX model is excluded the optional USB and RS485 interfaces.
To add additional interfaces on TERRA-IEX, please see the table of all TERRA-IEX model as below.
| TERRA-IEX | Mic/line-IN x 2, stereo line-OUT x 1 or mono x 2, input contact x3, relay output contact (NO/NC) each x1, RS232 x1 |
| TERRA-IEXU | Including all interfaces on TERRA-IEX, plus USB2.0 x 1 |
| TERRA-IEXU4 | Including all interfaces on TERRA-IEX except change the RS232 x 1 to RS485 x 1, plus USB2.0 x 1 |
